Meet the Demands of High-Voltage Testing with Aratas G3VH SiC MOSFET Relay
The transition to next-generation power semiconductors is increasing the need for reliable high-voltage switching. Designed for applications up to 3,300 V, the Aratas G3VH combines compact size, high reliability, and excellent insulation performance to support modern test and measurement systems.
Ideal for power semiconductor testing and other high-voltage DC applications, G3VH helps improve inspection accuracy while reducing test time, enabling more efficient evaluation of advanced power devices.
Benefits
- Improved accuracy in defect and conformance detection
- Reduced inspection time
- Supporting high voltage and high withstand voltage
- Rated voltage: 1,800V/3,300V
- input-output withstand voltage: 5,000V
Features
- High Voltage Rating
- Small-sized
- Long‑life and maintenance‑free
- Low on‑resistance
- High dielectric strength
- High‑speed ON/OFF switching
Designed for High-Voltage Switching
The G3VH is a SiC MOSFET relay designed for load voltages up to 1,800 V and 3,300 V, making it suitable for demanding high-voltage DC applications.
Optimized for Semiconductor Testing
As power semiconductor devices become more advanced, test systems must deliver greater accuracy and efficiency. G3VH supports improved defect and conformance detection while helping reduce inspection time in ATE and test equipment.
Compact, Reliable, and Maintenance-Free
Combining a compact package with high reliability, low on-resistance, high dielectric strength, and long-life operation, G3VH provides dependable switching performance for critical systems.
Supporting Emerging High-Power Applications
G3VH is well suited for power semiconductor test equipment, EV systems, energy infrastructure, industrial automation, and railway applications where higher voltage capability is increasingly required.
