Converters for cost-effective applications

  • R-78E, RBE, R1SE, ROE, RKE/H & REE series:
    1W in different housing types
  • Ideal for the interface isolation in large numbers
  • Pin-compatible with industry standard converters
  • No compromise at the operating temperature: -40°C to +85°C
  • R1SE suitable for vapor phase soldering
  • RKE/H available with 4kVDC isolation

Energy saving Mini AC/DC power supplies

  • Ultra-compact, low profile AC/DC modules (class II) with 3kVDC isolation
  • 1W to 10W modules for PCB mounting
    - no additional filter circuit required
  • Wide input voltage range (80-305VAC)
  • UL & CE certified and fully protected outputs
    (short circuit, overload and overheating)
  • Direct replacement for 7805 linear regulator and common TO-220-linear packages
  • Price effective, energy saving drop-in replacement solution
  • Full industrial temperature range of  -40°C to +85°C (+70°C without derating)
  • Allows operation from both an industrial 24V bus as well as from 9V, 12V or 24V battery systems
  • Fully protected against overload, short circuit and over-temperature conditions
  • Dimension: 11.6 x 8.5 x 10.4 mm
  Datasheet    Part number    Power (W)    Vin    Vout(VDC)    Iout (mA)    Outputs    Case    Isolation (kV)    SCP(cont.)
  Download as PDF     R-78E3.3-0.5    1.65    6-28 VDC    3.3    500    1    SIP3    -    yes
  Download as PDF     R-78E5.0-0.5    2.5    7-28 VDC    5    500    1    SIP3    -    yes
  Download as PDF     R-78E9.0-0.5    4.5    12-28 VDC    9    500    1    SIP3    -    yes
  Download as PDF     R-78E5.0-1.0    5    8-28 VDC    5    1000    1    SIP3    -    yes
  Download as PDF     R-78E12-0.5    6    15-28 VDC    12    500    1    SIP3    -    yes
  Download as PDF     R-78E15-0.5    7.5    18-28 VDC    15    500    1    SIP3    -    yes

Other: Cost Effective DC/DC Converters

  • Cost effective and high quality
  • 5V input/output and 1kVDC isolation
  • Operating temperature range of -40°C to +85°C
  • UL certified
  Datasheet    Part number    Power (W)    Vin    Vout(VDC)    Iout (mA)    Outputs    Case    Isolation (kV)    SCP(cont.)
  Download as PDF     ROE-0505S    1    5 VDC    5    200    1    SIP4    1    -
  • 5V input/output
  • 1kVDC isolation
  • Ideal for applications such as isolation for bus systems and interfaces
  • Operating temperature range of -40°C to +85°C
  • UL certifid
  Datasheet    Part number    Power (W)    Vin    Vout(VDC)    Iout (mA)    Outputs    Case    Isolation (kV)    SCP(cont.)
  Download as PDF     R1SE-0505    1    5 VDC    5    200    1    SMD 5 Pin, SMD 8 Pin    1    -
  • 5V input/output
  • 1kVDC isolation
  • Ideal for applications such as isolation for bus systems and interfaces
  • Operating temperature range of -40°C to +85°C
  • UL certified
  Datasheet    Part number    Power (W)    Vin    Vout(VDC)    Iout (mA)    Outputs    Case    Isolation (kV)    SCP(cont.)
  Download as PDF     RBE-0505S    1    5 VDC    5    200    1    SIP7    1    -
  • 5V input/output
  • 1kVDC isolation
  • Operating temperature range of -40°C to +85°C
  • UL certified
  Datasheet    Part number    Power (W)    Vin    Vout(VDC)    Iout (mA)    Outputs    Case    Isolation (kV)    SCP(cont.)
  Download as PDF     REE-0505S    1    5 VDC    5    200    1    SIP7    1    -
  • 5V input/output
  • 4kVDC isolation
  • Low output ripple
  • Industry standard pinout
  • UL certified
  Datasheet    Part number    Power (W)    Vin    Vout(VDC)    Iout (mA)    Outputs    Case    Isolation (kV)    SCP(cont.)
  Download as PDF     RKE-1205S/H    1    12 VDC    5    200    1    SIP7    4    -
  Download as PDF     RKE-2405S/H    1    24 VDC    5    200    1    SIP7    4    -
  Download as PDF     RKE-0505S/H     1    5 VDC    5    200    1    SIP7    4    -

Other: Low Power AC/DC Converters

  • Universal 100-240VAC input range
  • 2W power output
  • Operating temperature range of -25°C to +75°C
  • Standby power consumption as low as 30mW
  • UL, EN & CB certified
DatasheetPart numberPower (W)VinVout(VDC)Iout (mA)OutputsCaseIsolation (kV)SCP(cont.)
Download as PDFRAC02-05SC280-264 VAC54001Standard3yes
Download as PDFRAC02-12SC280-264 VAC121671Standard3yes
  • Extended 100-277VAC input range
  • 3W power output
  • Operating temperature range of -40°C to +85°C
  • Standby power consumption <30mW
  • UL, EN & CB certified
DatasheetPart numberPower (W)VinVout(VDC)Iout (mA)OutputsCaseIsolation (kV)SCP(cont.)
Download as PDFRAC03-05SE/277380-305 VAC56001Standard3yes
Download as PDFRAC03-12SE/277380-305 VAC122501Standard3yes
  • Extended 100-277VAC input range
  • 3W power output
  • Flying wire leads
  • Operating temperature range of -40°C to +85°C
  • Standby power consumption <30mW
  • UL, EN & CB certified
DatasheetPart numberPower (W)VinVout(VDC)Iout (mA)OutputsCaseIsolation (kV)SCP(cont.)
Download as PDFRAC03-12SE/277/W385-305 VAC122501Standard3yes
Download as PDFRAC03-05SE/277/W385-305 VAC56001Standard3yes

These featured products are a small selection from our 30,000+ part number portfolio. Further products can be found through our parametric search.
